About

Elite 444 is a multi-line three-phase digital panel meter for accurate and reliable measurement of electrical parameters (voltage, current, power, frequency, etc.) for industrial and commercial applications. It has a large multi-line backlit LCD display which enables four parameters to be displayed at the same time. Modbus communication capability allows easy integration with energy monitoring systems. Expansion modules can be fitted for enhanced system integration (pulse inputs/outputs or analogue output and ethernet). Active Total Import / Export Energy. Reactive Import (Q1+Q2) / Export (Q3+Q4) Energy. Cumulative MD, Phase Angle, Power On / Off Hours, Load On / Off Hours, Feeder Interruptions Count (When Aux is also off), THD Voltage, THD Current, THD Power, RPM with Freq and VUnb and IUnb, Modbus on RS 485. Active / Apparent Forwarded Energy, Reactive Lag / Lead Forwarded Energy.


Exceptional Functionality for Electrical Monitoring

Elite 444 ensures comprehensive real-time monitoring of electrical parameters, including voltage, current, power, frequency, power factor, and energy, providing clarity and control for industrial and commercial applications. Its highly accurate measurements help maintain compliance and system reliability.


Robust Design Meets Safety Standards

Engineered for demanding environments, the Elite 444 features an IP54 protection system and ABS flame retardant enclosure. This design complies with IEC 61010-1 and IEC 61326 standards, assuring operational safety, insulation, and resilience against shocks and vibrations.


Advanced Communication and Data Storage

With the RS485 MODBUS RTU communication interface and non-volatile memory, users benefit from easy remote monitoring and secure parameter storage. This facilitates integration into automated control systems and supports reliable data retention.
